Opel Z20LET E85 875cc EFR6758 400Hk - VEMS tune

Opel Z20LET E85 875cc EFR6758 400Hk - VEMS tune

€27.15
Complete tune for Opel Z20LET. Injector: Siemens Deka 875cc Fuel: E85 Turbo: Borg Warner EFR6758 Power: 360hp and 480nm on the front wheels. NOTE: If you have bought syringes from us, do not buy the Base Tune, it is included :) ---- NOTE all driving is at your own risk! ---- Firmware: 1.2.31 4cyl standard 60-2 trigger + cam sync Trigger Offset: 106 degrees Pinouts: Injectors: 7, 19, 8, 20 Ignition: 34, 24,10, 36 in tändföld. Idle motor on pin 17 Boost control on pin 18 Fuel pump pin 15 Tachometer pin EC18 Pin4 Fan: Pin 3 WBO: LSU 4.9 Backwards compatible with previous firmwares, but we recommend updating to 1.2.31
Read more...
  • Secure payment by card
  • E-mail us, we reply swiftly!

Description

Article no.: 404

Pinouts: Ignition coils: Cyl1: 35 Cyl2: 33 Cyl3: 10 Cyl4: 24 Cyl5: 11 Cyl6: 12 Injector: 1 = pin 7 2 = pin 19 3 = pin 9 4 = pin 20 Fan/Low: pin 17 Fuel pump: Pin 6 Tacho: Ec36 pin 4 Boost pin 34 Rev limit: 6500 BoostLimit: 220Kpa 1.2bar
