BMW M52B28 Original engine M50 Insug 242hp 290nm
€27.15
Finished folder for standard M52B28 with M50 Intake and sports exhaust system
Injector: Original M52B28
Fuel: RON 95 Oct Gasoline
Turbo: -
Power: 242hp and 290nm in the engine
NOTE if you have bought spray from us, do not buy basic folder, it is included :)
---- NOTE all driving is at your own risk! ----
Firmware : 1.2.31
WBO: LSU 4.9
Backward compatible with previous firmwares, but we recommend updating to 1.2.31
- Secure payment by card
- E-mail us, we reply swiftly!
Description
Article no.: 470
Pinout:
Ignition coils:
Cyl1: 33
Cyl2: 11
Cyl3: 34
Cyl4: 36
Cyl5: 12
Cyl6: 35
Sprocket:
1 = pin 7
2 = pin 19
3 = pin 8
4 = pin 20
5 = pin 9
6 = pin 18
Fuel pump: pin 6
Tacho: Ec36 pin 4
Idle: pin 24
Vanos: pin 17
Rev limit: 7000
BoostLimit: -
